De 6TL-08 Universal.

De fastATE 6TL-08 en 6TL-08W, compacte universele testsystemen. De 6TL-08 is een compact universeel testplatform waarbij testfixture en meetelektronica zijn geïntegreerd in één compacte behuizing. Door het gebruik van de 6TL fastATE technology is de 6TL-08 uitermate modulair en flexibel in zijn configuratie en gebruik. Of het nu gaat om een eenvoudige verificatie tester of een geavanceerd op PXI gebaseerde functionele tester het is allemaal mogelijk binnen het 6TL-08 concept. Ook beginnen met een eenvoudige 6TL-08 Basic, welke is te programmeren via Excell, en later uitgroeien naar een 6TL-08 universal welke te programmeren is via bijvoorbeeld Labview of Testsand, is…

Lees verderDe 6TL-08 Universal.

6TL FastATE In-Line Test Handlers.

Optimize & shorten your production-test, using 6TL FastATE In-Line Test Handlers. (Case Study) 6TL32 FastATE In-Line Test Handlers for ICT Test, In a world where electronics play a vital role, ensuring the quality and efficiency of printed circuit boards (PCBs) has become crucial. Conducting In-Circuit tests is essential to identify potential faults in components and ensure the proper functioning of electronic devices. This case study focuses on an electronics manufacturing company facing significant challenges in conducting in-circuit tests efficiently and accurately. Download 6TL36 in-line Brochure Test requirements. An ICT (In-Circuit Test) is a testing method used in the manufacturing…

Lees verder6TL FastATE In-Line Test Handlers.

Het belangrijkste in een testsysteem is een betrouwbaar contact.

Waarom is bij een testsysteem voor elektronica een goed contact zo belangrijk? Om een meting te kunnen doen aan een elektronische printplaat moet je contact maken tussen het meetinstrument aan de ene zijde en de elektronica aan de andere zijde. Bij een digitale multimeter (DMM) doe je dit dan met twee testpennen welke je met de hand verbindt met de te meten posities op de te testen print. Hetzelfde geld voor het programmeren van elektronica, ook dit wordt vaak gedaan met behulp van een stekkertje op de print of hand tooltje op de programmeerposities. We weten allemaal dat als…

Lees verderHet belangrijkste in een testsysteem is een betrouwbaar contact.

Infinity Connector

An Infinite Number of Connections VPC's latest high speed technology allows for concerns about cycle life and lost time due to PCB soldering and change out to be a thing of the past. The unique design of VPC's VTAC, QuadraPaddle, and Micro Power SIM connectors allows for change out and replacement of pass-thru inserts while preserving the right angle connection to the PCB.  VPC's SIM module offers up to 34 positions and allows for mixed input/output combinations. Experience the infinity Connector yourself. See below to learn more on the new VPC infinity connector. https://youtu.be/KOA32QtcpE4 Download more information in PDF. Specifications QuadraPaddle Operating Voltage &…

Lees verderInfinity Connector
Lees meer over het artikel 50GHz RF Coax Contacten en Patchcords van VPC.
VPC 90 series front view of 9025 Mass Interconnect receiver (test system side)

50GHz RF Coax Contacten en Patchcords van VPC.

Mass interconnect is een must voor betrouwbare testsystemen. Een slecht contact tussen de meetinstrumentatie en uw te meten of te testen product kan direct leiden tot ongewenste afkeur en zeker bij hogere frequenties tot onnodige hoge kosten. Door de steeds verder voortschrijdende techniek waarbij steeds hogere frequenties en datasnelheden de standaard worden is het vanzelfsprekend dat naast een betrouwbaar contact ook een minimaal verlies in de bekabeling van groot belang is.

Lees verder50GHz RF Coax Contacten en Patchcords van VPC.

High Speed problems within Pylon Interfaces.

Typical Pylon Interface setup. Pylon interfaces are one of the oldest Mass Interconnect interfaces that are still being used and widely available on the market for a very long time. At  the time they were developed as a reliable interface solution for (Genrad) ICT test systems, based on a standardised block with 170 Pylon or POGO test-probes on the tester side (Receiver) and a counter contact block inside each test fixture (ITA). As over the years we moved to surface mount technology and more complex and compact digital boards we moved also more and more from In-Circuit to Functional…

Lees verderHigh Speed problems within Pylon Interfaces.
Lees meer over het artikel YAV90MMU, 4¾ Digit DMM with 16-Ch Mux
YAVModules Switches, Matrix and Multiplexors.

YAV90MMU, 4¾ Digit DMM with 16-Ch Mux

YAV90MMU Programmable Measurement Unit 4¾ digit True RMS Auto-Range, up to 600 VAC VAC, VDC, Ohms, Pt100, IAC, IDC, Capacitors, Diodes Frequency meter (Up to 400 MHz) and Duty Cycle (Up to 1 MHz) Peak hold function Scanner x16 [600VRMS Measurement Channels] Dielectric Withstanding Voltage (DWV) >1500V between Measurement Channels Two isolated and programmable pulse generator channels. Selectable output voltage. External Trigger-In and Trigger-Out SMB connectors CAN bus or Ethernet control Ethernet to CAN bus gateway 8 Programmable digital outputs (PNP 24VDC 300mA) Up to 10 readings per second High quality connector module (> 20.000 mates) Built-in test steps…

Lees verderYAV90MMU, 4¾ Digit DMM with 16-Ch Mux

Oversized EMI Backshell for iCon 2 Module ITA.

The iCon XL Een belangrijke upgrade van de Virginia Panel Corporation iCon familie Mass Interconnect connectoren, waarbij door de introductie van de iCon XL nu ook, voor oplossingen waarbij veel power en coaxiaal contacten worden gebruikt, voldoende ruimte is om deze te integreren.De iCon XL biedt een extra grote U-vormige kabelklem welke bedrading van de modules vooraf mogelijk maakt en ruimte biedt aan kabelbundels tot een effectieve diameter van 49,5mm bij een effectieve buigradius van ruim 25mm. De beschermkap kan, net als bij de reguliere uitvoeringen eenvoudig naar voren worden afgeschoven voor eenvoudig contact met de bekabeling voor debug…

Lees verderOversized EMI Backshell for iCon 2 Module ITA.

Fully Automated In-system programming (ISP)

What is ISP (In-System Programming)  In-system programming (ISP), also called in-circuit serial programming (ICSP), is the ability of some programmable logic devices, microcontrollers, and other embedded devices to be programmed while installed in a complete system, rather than requiring the chip to be programmed prior to installing it into the system. It allows firmware updates to be delivered to the on-chip memory of microcontrollers and related processors without requiring specialist programming circuitry on the circuit board, and simplifies design work.  There are several mutually-incompatible in-system programming protocols for programming microcontroller devices, including PIC microcontrollers, AVRs, and the Parallax Propeller. ICSP has been primarily implemented by Microchip Technology for programming PIC and…

Lees verderFully Automated In-system programming (ISP)
Lees meer over het artikel VTAC Mass interconnect interface Patchcords
VPC 90 series front view of 9025 Mass Interconnect receiver (test system side)

VTAC Mass interconnect interface Patchcords

USB-C Patchcord Een veel gebruikte interface is tegenwoordig de USB-C interface. Deze interface wordt steeds vaker ook gebruikt als communicatie interface in moderne meetinstrumenten maar ook in steeds meer nieuw ontwikkelde applicaties. Hierdoor was de noodzaak aanwezig om ook een USB-C patchcord toe te voegen aan het bestaande, beschikbare pallet van Mass Interconnect patchcords. Mass Interconnect Interface. Een Mass Interconnect Interface van VPC is haast een vanzelfsprekende toevoeging aan een test rack als betrouwbaarheid en flexibiliteit en modulariteit van belang zijn bij het ontwikkelen van de testapplicatie.  Om een Mass Interconnect Interface te verbinden met de in het test…

Lees verderVTAC Mass interconnect interface Patchcords
